NGC 7354

Also Known as: PN G107.8+02.3 IRAS 22384+6101

Object Type: Planetary Nebula

Constellation: Cepheus

Distance from Earth: 5,538 light years

Apparent Magnitude: 12.2

Coordinates: RA 22H 40M 19.87387 Sec DEC 61 deg 17 min 08.7444 sec

Actual Size: The inner ring is 0.4 light years across, the outer around 0.6 light years.

Apparent Dimensions: 23 arcseconds

--------------------------------------------------------------------------

Environmental Data

Date: July 8, 2026     Start Time: 9:37 PM    End Time: 3:07 AM    SQM: 18.42

Moon Age: 22.6 days     Moonrise: 0:04 AM     Moon Illumination: 45.4%

Temperature: 73 degrees F    Humidity: 74%    Dew Point: 64.2 degrees F

Location: Westport, Massachusetts 02790    Sky Condition: Clear

Comment: Ran PHD2 Guidance assist and PHD2 calibration

--------------------------------------------------------------------------

Imaging Scope Data

Mount: iOptron CEM120     Camera: ZWO ASI2600 monochrome     Focuser: Optec QuickSync FT20

Telescope: Celestron 11 inch SCT Edge   Focal Length: 2800mm

Focal Reducer/Field Flattener: None     Dew Heater: Kendrick dew strip

Filter Wheel : ZWO EFW 7 position 2 inch  Filter(s): Baader Lum CMOS optimized 2 inch, Baader RED CMOS optimized 2 inch, Baader GREEN CMOS optimized 2 inch, Baader BLUE CMOS optimized 2 inch

Rotator: Pegasus Falcon 2     Power Control: Pegasus Ultimate Powerbox V2

Imaging Software

Mount: iOptron Commander     Focuser: Optec FocusLynx Commander

Imaging: Sequence Generator Pro     Platesolve: ASTAP (native)    Rotator/Control: Pegasus Unity Platform

Imaging Status

Imaging Software: Sequence Generated     Focus HFR 3.85     Platesolve: Success on 3th attempt

--------------------------------------------------------------------------

Guide Scope Data

Telescope: Stellarvue SVX130 refractor    Camera: ZWO ASI290     Focuser: Optec DirectSync SV35

Dew Heater: Kendrick dew strip    Software: PHD2    Exposure: 1 sec    Binning: 1x1    Tracking Result: 0.59-0.9 arc-seconds RMS

--------------------------------------------------------------------------

Images Taken

Number of light frames (LUM): 30        Duration: 2 minutes        Gain: 100

Number of light frames (Red): 40        Duration: 2 minutes        Gain: 100

Number of light frames (green): 40        Duration: 2 minutes        Gain: 100

Number of light frames (Blue): 40        Duration: 2 minutes        Gain: 100

Camera Temperature: 0 degrees C        Binning: 1x1        F-Stop: 10.0

Total Integration Time: 5 hours

--------------------------------------------------------------------------

Number of flat frames (LUM): 25        Duration: 0.11        Gain:100

Number of flat frames (Red): 25        Duration: 0.36        Gain: 100

Number of flat frames (Green): 25        Duration: 0.23        Gain: 100

Number of flat frames (Blue): 25        Duration: 0.48        Gain: 100

Flat Field Illumination: All-Pro 'Spike-a-Flat Field standard' illuminated panel

--------------------------------------------------------------------------

Number of Dark frames: 50 (from library)       Duration: 2 minutes        Gain: 100

Number of Bias frames: 50 (from library)      Duration: 0.001 seconds        Gain: 100

--------------------------------------------------------------------------

Imaging Processing

Imaging Processing Software: PixInsight

Processes utilized: Linear - calibration/integration: For each of the LUM, RED, GREEN, BLUE, Flats ImageCalibration with Master Bias, Flat ImageIntegration, Images ImageCalibration with Flat Master & Dark Master, SubFrameSelector
StarAlign all calibrated lights using best LUM image as reference, ImageIntegration of each of the LUM, RED, GREEN, and BLUE sets
Seti_Astro SASpro cosmic clarity satellite trail removal tool to remove trails on all images prior to performing integration.

Linear - Background extraction, Color correction, deconvolution, noise reduction:
LUM DynamicCrop, GraXpert, BlurXTerminator, NoiseXterminator.
RED/GREEN/BLUE DynamicCrop, GraXpert, ChannelCombine to create color image using only Red/Green/Blue, BlurXTerminator, NoiseXterminator, Image Solver script, SpectroPhotometricColorCalibration

Non-Linear: LUM: MultiscaleAdaptiveStretch, BlemishBlaster script to remove artifacts, MultiScaleLinearTransform to sharpen, GAME script to create mask, MultiScaleLinearTransform ro sharpen only the nebula.
Color:MultiscaleAdaptiveStretch, MultiScaleLinearTransform to sharpen
ImageBlend script to combine LUM and COLOR/Narrowband masters, GAME script to create mask, MultiScaleLinearTransform, CurvesTransformation to increase blue and red channels. BlurXterminator to sharpen stars and nebula slightly, DynamicCrop

--------------------------------------------------------------------------

Notes:

Click Below Image for Full Size:
